4DigitalBook DL-Mini Auto-Flip Book Scanner – The perfect combination of image quality and productivity for your automatic book scanning requirements.

About

4DigitalBooks Robotic Scanners

4DigitalBook DL-Mini Auto-Flip Book Scanner – The perfect combination of image quality and productivity for your automatic book scanning requirements.

The 4DigitalBook DL-Mini is equipped with a suction-assisted page-turner and an air-cushioned book holder. These two systems ensure that the works are handled without applying any pressure and that the binding undergoes no strain.

DL-mini automatic flip book scanner suitable for books, magazines and bound newspapers – Up to A2 format scanning surface suitable for 24 hours / 7 days operation, with Constant Image Quality, Reliable Page Turning and Highest Book Safety.

4DigitalBook DL-Mini is designed for Large Volume of Book Digitization of any bound material that significantly increases the net throughput and lowers the overall costs of your digitization projects.

No need choosing between automatic or manual scanner, you have both in ONE !
Uniquely, the DL-mini is an automatic and manual book scanner for any kind of documents, it will accepts books up to double A3, unusual documents such as photo albums, stamp albums, spiral, bound notebooks, postcards, photos, manuscripts … and Allows scanning exceptions found in bound documents such as lose sheets, inserts, fold-outs, bent pages, torn pages, covers …

Dl-mini detects double pages and automatically retries page pickup, insuring one page turn at a time and less operator interventions. Reaches consistent productivity of 1300 pages per hour and max speed of 2000 pages per hour for quick scanning of easy books.

DL Mini

Features

Auto detection and adapts to parameters of the book
Suitable for 24 hour – 7 day operation
Auto Double Page Detection
Adjustable scan speeds for fragile books
2 x A3 (600 x 420 mm / 17” x 24”) scanning surface
Scan books as small as A6 size (105 x 148 mm)
Scan hard and soft cover books
Scan glass provides perfectly flat images with every scan
Ensured one page turn at a time, no missing pages
Suitable for recent and old books
Accepts books with any paper thickness, texture, and porosity

Built-in Centered Book-Cradle
10 Kgs Maximum Book Weight
100 mm Maximum Book Thickness
From 20 g/m2 up to 200 g/m2 Paper Weight
Vacuum Palatines Book Holding Technology
Distributed Vacuum Arm Page Picking Mechanism
Fully Equipped with Operation Workstations and Monitor
No Consumables
Average productivity 10,000 pages per shift (300, 400 dpi)
Recommended Maintenance Once per Year
Full Remote Access capability for technical support and diagnosis, user assistance and training.

SCANNER

MODELS


DL-mini-E-600
DL-mini-I 400
DL-mini-C 400
DL-mini-C 300
Integrated Camera1x CopiBook EXTRA Digital Camera1x CopiBook 400 Digital Camera2x Canon EOS 5 DSR Digital Camera1x Canon EOS 5 DSR Digital Camera
Image Size Matrix156 Mega-Pixels Camera63 Mega-Pixels Camera50 Mega-Pixels Camera50 Mega-Pixels Camera
Resolution300, 400 & 600 dpiMinimum 200 dpi / Maximum 400 dpiMinimum 200 dpi / Maximum 400 dpi (Optional 600 dpi for A4 Books)Minimum 200 dpi / Maximum 300 dpi
Productivity per hourUp to 1300 pages Consistent & 1500 max productivityUp to 1000 pagesUp to 1500 pagesUp to 1500 pages

DOCUMENT

ACCEPTED

  • Book weight: max. 10 kg
  • Book thickness: max. 100 mm
  • Minimum Page Size: min A6 (105 x 148 mm)
  • Maximum Page Size: A3 (297 x 420 mm)
  • Scanning surface: max A2 (600 x 420 mm)
  • Opening angle of pages: 180°
  • Paper weight: min. 20 g/m2, max. 200 g/m2
  • Wavy pages or covers: max. amplitude 10 mm

DELIVERY

Maintenance

Delivery

4DigitalBook DL-Mini Delivery Includes “Complete Ready to Use”
Scanner, Camera( s) and LED lights.
Page Turner with Vacuum Pump and Pipes.
PC-Scan Computer with i7 CPU, 8 GB RAM, Windows 10 PRO
24″ Monitor, Keyboard, MouseFoot Switch.
1 TB ultra fast Local Storage.
Page Improver Scanning Software.
PC-Remote Computer (for Canon cameras only).
Robust Table on Wheels.

Maintenance

DL-mini has ZERO consumables
Heavy Duty cycle of 24 hours per day, 7 days per week.
Recommended maintenance after every year of operation, once per year.
Full remote control capability for technical support and diagnosis, user assistance and training.

Click the link below to see a video for the DL-Mini Auto-Flip Book Scanner now.

4DigitalBooks catalogue

Click the link below to download the product catalogue now.
