BookTEC & WideTEK Scanners

Image Access has the widest portfolio of products in the industry. Archives, libraries, museums, government and industry can digitize and produce the highest quality image output at the fastest speed available wide format originals up to 60 inches wide with the book scanners, flatbed scanners, sheet-feed scanners and the unique art non-contact overhead scanners WideTEK 36ART & 60ART

ImageAccess

BookTEK Book Scanners

Manual Flip, Archive & Semiautomatic Book Scanners suports A1, A2 & A3 media Sizes

BookTEK 5 V3 Scanners

  • Overhead scanner for A3+ formats (size 390 x 480 mm)
  • 3 Models: Basic (400 dpi, Mono), Kiosk (400 dpi, Color) & PRO (600 dpi, Color)
  • 0.8 second at 150 dpi scan speed
  • Built-in Computer & bundled with 21 inch multi-touch screen
  • CCD line sensor, 22,500 Pixel Matrix Camera
  • Complies to FADGI *** guidelines, Metamorfoze Light, ISO 19264-1
Brochure

BookTEK 5 V2 Scanners

  • Overhead scanner for A2+ formats (size 460 x 620 mm)
  • 3 Models: Basic (400 dpi, Mono), Kiosk (400 dpi, Color) & PRO (600 dpi, Color)
  • 0.9 second at 150 dpi scan speed
  • Built-in Computer & bundled with 21 inch multi-touch screen
  • CCD line sensor, 22,500 Pixel Matrix Camera
  • Complies to FADGI *** guidelines, Metamorfoze Light, ISO 19264-1
Brochure

BookTEK 5 V1A Scanners

  • Overhead scanner for A1+ formats, size 635 x 914 mm (25 x 36 inch)
  • Color, High resolution line sensor with 600 x 600 dpi
  • 1.2 seconds at 150 dpi scan speed
  • Built-in Compute, 7 inch color WVGA touchscreen & bundled with 27 inch 4K screen
  • CCD line sensor, 22,500 Pixel Matrix Camera
  • Exceeds FADGI ** guidelines, MF Light, ISO 19264-1
Brochure

BookTEK 5 V3A Automatic Scanner

  • 390 x 480 mm (15.3 x 18.9 inch), 50% more than DIN A3
  • 0.8 second scan speed @ 150 dpi DIN A3+
  • 600 dpi, 48 bit Color Depth, 24 bit color Scan Output
  • CCD line sensor, 22,500 pixels (11,000 scan lines equals to a 245 MPixel matrix camera)
  • CMOS matrix Live Preview Camera
  • Magnetically coupled V-shaped book cradles 120 – 180 degrees
  • Motor-driven V-shaped glass plate for perfect scans
  • Scan2USB — Direct output to the integrated USB-Port
  • Scan2Net® — Output to SMB, FTP, Printer, Email
  • Built-in PC with 21″ FHD Multi-Touch screen
  • Complies to FADGI *** guidelines, Metamorfoze Light & ISO 19264-1
Brochure

BookTEK 5 V2A Automatic Scanner

  • 460 x 620 mm (18 x 24 inch), 14% more than DIN A2
  • 0.9 seconds scan speed @ 150 dpi DIN A2+
  • 600 dpi, 48 bit Color Depth, 24 bit color Scan Output
  • CCD line sensor, 22,500 pixels (11,000 scan lines equals to a 245 MPixel matrix camera)
  • CMOS matrix Live Preview Camera
  • Magnetically coupled V-shaped book cradles 120 – 180 degrees
  • Motor-driven V-shaped glass plate for perfect scans
  • Scan2USB — Direct output to the integrated USB-Port
  • Scan2Net® — Output to SMB, FTP, Printer, Email
  • Built-in PC with 21″ FHD Multi-Touch screen
  • Complies to FADGI *** guidelines, Metamorfoze Light & ISO 19264-1
Brochure

BookTEK 5 V2 Archive Scanner

  • Unique self-adjusting and V-shaped book cradle with motor driven glass plate
  • 460 x 620 mm (18 x 24 inch), 14% more than DIN A2
  • 0.9 seconds scan speed @ 150 dpi
  • 600 dpi, 48 bit Color Depth, 24 bit color Scan Output
  • CCD line sensor, 22,500 pixels (11,000 scan lines equals to a 245 MPixel matrix camera)
  • Self-adjusting V-shaped book cradle 120 – 180 degrees can lift 10 cm
  • Motor driven V-shaped glass plate for perfect scans
  • Scan2USB — Direct output to the integrated USB-Port
  • Scan2Net® — Output to SMB, FTP, Printer, Email
  • Built-in PC with 21″ FHD Multi-Touch screen
  • Complies to FADGI *** guidelines, Metamorfoze Light & ISO 19264-1
Brochure

Looking for a Robotic Auto-Flip Book Scanner?

LATEST CATALOG
Scan2Net Technology

ImageAccess

WideTEK Wide-Format Scanners

Ultra Fast Color CIS 36, 48 & 60 inch wide Scanners
“also available in CCD Scan Technology in 36, 44 & 48 inch wide”

WideTEK 36CL Scanner

  • 96.5 cm (38 inch) scan width
  • 1200 x 1200 dpi Resolution
  • Scan Speed: Mono 22.9 meter/minute (15 inch/second) & Color 15 meter/minute (10 inch/second) at 200 dpi
  • Built-in Computer & bundled with 21 inch multi-touch screen
  • 3x CIS modules, 22,389 pixels, encapsulated and dust-proof Camera
  • Complies to FADGI *** guidelines and ISO 19264-1
Brochure

WideTEK 48CL Scanner

  • 127 cm (38 inch) scan width
  • 1200 x 1200 dpi Resolution
  • Scan Speed: Mono 22.9 meter/minute (15 inch/second) & Color 11.4 meter/minute (7.5 inch/second) at 200 dpi
  • Built-in Computer & bundled with 21 inch multi-touch screen
  • 4x CIS modules, 29,852 pixels, encapsulated and dust-proof Camera
  • Complies to FADGI *** guidelines and ISO 19264-1
Brochure

WideTEK 60CL Scanner

  • 157 cm (61.85 inch) scan width
  • 1200 x 1200 dpi Resolution
  • Scan Speed: Mono 22.9 meter/minute (15 inch/second) & Color 9.1 meter/minute (6 inch/second) at 200 dpi
  • Built-in Computer & bundled with 21 inch multi-touch screen
  • 5x CIS modules, 36,720 pixels, encapsulated and dust-proof Camera
  • Exceeds FADGI *** guidelines, ISO 19264-1
Brochure

ImageAccess

WideTEK Flatbed Scanner

WT36 (A1+), WT25 & WT24F (A2+) & WT12 (A3+) Media Size

WideTEK 24F Scanner

  • Borderless, fully scratch-resistant glass plate prevents bent edges on source documents and allows scanning of oversized documents
  • Document Size 610 x 457 mm (24 x 18 inch), 11% > DIN/ISO A2
  • 1200 x 1200 dpi Resolution
  • 4 seconds Scan Speed (max. document size) in Color at 300 dpi
  • CIS line sensor with long focal selfoc lens, depth of focus > +-1mm @600dpi Camera
  • Captures 3D surfaces, textures of various materials, Braille print
  • 7″ built-in 1280*800 color multitouch screen
Brochure

WideTEK 25 Scanner

  • Borderless glass plate prevents bent edges on source documents. Scratch resistant & non-reflective
  • Document Size 635 x 470 mm (25 x 18.5 inches), 19% > DIN A2
  • 1200 x 1200 dpi Scanner Resolution
  • 3 seconds Scan Speed (max. document size) in Color at 300 dpi
  • 2x Tri-Color CCD camera, 45,000 pixels Camera
  • Captures 3D surfaces, textures of various materials, Braille print
  • Optional backlight for transparent source material, like X-rays, film, negatives and more
Brochure

WideTEK 12 Scanner

  • Borderless glass plate prevents bent edges on source documents. Scratch resistant & non-reflective
  • Document Size 317x 470 mm (12.5 x 18.5 inches), 19% > DIN A3
  • 1200 x 1200 dpi Resolution
  • 3 seconds Scan Speed (max. document size) in Color at 300 dpi
  • Tri-Color CCD camera, 45,000 pixels Camera
  • Captures 3D surfaces, textures of various materials, Braille print
  • Optional backlight for transparent source material, like X-rays, film, negatives and more
Brochure

WideTEK 36F Scanner

  • World´s fastest DINA1+ flatbed with CIS-cameras is highly accurate and easy to operate.
  • Document Size 915 x 610 mm (36 x 24 inch),11% more than DIN/ISO A1
  • 1200 x 1200 dpi Resolution
  • 6 seconds Scan Speed (max. document size) in Color at 300 dpi
  • Three CIS line sensors with long focal selfoc lens, depth of focus > +-1mm @600dpi
  • Desktop version with Optional Floor Stand
  • Scan directly to SMB, FTP, hot folders, USB, Email or the Cloud
Brochure

WideTEK 12-Spectrum Scanner

  • Fastest UV, VIS, IR, 3D and Backlight Flatbed Scanner in A3+ (12 x 18 inch) Format
  • Document Size 317x 470 mm (12.5 x 18.5 inches), 19% > DIN A3
  • 1200 x 1200 dpi Resolution
  • VIS & IR @ 300 dpi < 3 seconds, @ 600 dpi < 6 seconds, @ 1200 dpi < 12 s; UV @ 300 dpi 12 seconds
  • Tri-Color CCD camera, 45,000 pixels Camera
  • Captures 3D surfaces, textures of various materials, Braille print
  • Optional backlight for transparent source material, like X-rays, film, negatives and more
Brochure

Perfecting the Art of Art Scanning

WideTEK Art Large format scanner designed specifically for fine art scanning

WideTEK® 36ART & 60ART enables contact free scanning of works of fine art like oil and acrylic paintings, watercolors, charcoal and pastel drawings, mixed media collages and antique works of art; at 600dpi in formats up to 36 x 60 inch (WT36ART) & 60 x 80 inch (WT60ART). Optionally for the WT36ART, a scan table extension of 700 mm (27.6 inches) can be purchased which allows originals up to a length of 2224 mm (87.6 inches) to be scanned.

The WideTEK ART was designed for archiving and reproduction of works of art. Museums can digitize their own collection for sale as a print or for publication on the internet or in catalogs.

Original artwork is moved under the CCD camera elements completely contact free, protecting the art from any damage and making it possible to scan a painting that is still wet, as long as it is framed or the sides are dry enough to place the artwork on the scanning bed.

WideTEK® 36ART Brochure
WideTEK® 60ART Brochure
Artifacts Scanning
WideTEK 36ART-600
  • 914 x 1524 mm (36 x 60 inches) Maximum Document Size with optional scan table extension 914 x 2224 mm (36 x 87.6 inches)
  • Maximum Scan Height of 100 mm (4 inch)
  • Document Thickness 200 mm (8 inch) | Canvas up to max. 100 mm in a frame up to 200 mm thickness
  • 3x Tri-Color CCD Camera, 67.500 pixels, encapsulated and dust-proof
WideTEK 60ART-800
  • 1524 x 2032 mm (60 x 80 inches) Maximum Document Size. This is suitable for almost all commercially available canvas formats
  • Maximum Scan Height of 140 mm (5.5 inch)
  • Document Thickness 240 mm (9.5 inch) | Canvas up to max. 140 mm in a frame up to 240 mm thickness
  • 5 x Tri-Color CCD Camera, 112,500 pixels, encapsulated and dust-proof

Add-On to BookTEK & WideTEK - Scan2Pad

Scan2Pad® – Flexible Scanning from Smart Phone, iPad or Android Tablet

Scan2Pad® allows Image Access scanners to be controlled using an iPad or an Android tablet or smartphone running Android version 4.0.3 or higher. Experience a new way to work with our book scanners and large format scanners and see how simple it is to operate them using our mobile technology, Scan2Pad®.

More Information

Add-On to WideTEK Scanners - PerfectStitch

The Easiest Way to Make One Out of Two!

The PerfectStitch software is the easiest, most intuitive solution for fast and accurate stitching of two JPEG and TIFF images. Using the high quality images generated by Image Access scanners, you can achieve a perfect stitching result in three simple steps. Double the scan area of your Image Access Scanner with PerfectStitch!

More Information

Add-On to WideTEK Scanners - PrintWizard

Fully Featured Wide Format MFP Solution with No Compromises

The PrintWizard converts every WideTEK scanner to a powerful MFP system by adding the printer of your choice. PrintWizard maintains full control of all features of the attached printer and allows the user to define and manage workflow with individual scanner, printer all on one device, the scanner. Supports a wide range of printers from Epson, Canon, Océ & HP.

More Information
Scan2OCR
ScanWizard

Batch Scan Wizard
